Academic Labs

CAD Lab – List of Equipment
S. No. Name of the Equipment Quantity
1 HP COMPUTER
AMD Phenom IIX4, 3.20 GHz, 4 GB RAM, 500GB HDD,
ZOTAC NVIDIA GeForce 210 Graphics Card, 19” LED Color Monitor,
Scroll Mouse, Keyboard
33
2 HP COMPUTER 120
3 HP design Jet 500 A-0 Size Plotter 1
4 TVSE PRINTERTVS-MSP 245 XL – CLASSI Dot Matrix Printer 1
5 PRINTEREPSON Dot Matrix Printer 1
6

Software

  • AUTODESK INVENTOR SERIES
  • BRICS CAD
  • INTELLI CAD
  • ANSYS 8
  • Pro/Engineering (Wild Fire) Creo
  • Hyper Works - 13
  • Solid Works - 12
  • ADAMS Motion Bundle (Purchased through Fast Track Funding Ref # SERC/ET-0259/2011) from DHT
  • ANSYS Fluent – 13 (CFD)

FM & HM Lab – List of Equipment
S. No. Name of the Equipment Quantity
1 Open Channel Flow Apparatus 1 Set
2 Triangular Notch (V-Notch) 1 Set
3 Rectangular Notch 1 Set
4 Mouth Piece 1 Set
5 Orifice 1 Set
6 Reynolds Apparatus 1 Set
7 Bernoulli`s Theorem Apparatus 1 Set
8 Pipe Friction Apparatus 1 Set
9 Minor Possess Apparatus 1 Set
10 Venturimeter & Orificemeter 1 Set
11 Reciprocating Pump 1 Set
12 Centrifugal Pump 1 Set
13 Pelton Wheel Turbine 1 Set
14 Kaplan Turbine 1 Set
15 Francis Turbine 1 Set
16 Centrifugal Pump at Rated Speed 1 Set
17 Gear Oil RPM 1 Set
18 Hydraulic Ram 1 Set
19 Impact Of Jet 1 Set
20 Velocity Measuring Flow 1 Set
21 Cut Secton Models Of Pumps 1 Set
22 Cut Section Modulus Of Valves 1 Set
Thermal Sciences (Heat Transfer, IC Engines, Thermal Engineering) Lab – List of Equipment
S. No. Name of the Equipment Quantity
1 4 Stroke 4 Cylinder Petrol Engine With Hydraulic Dynamometer (Ambassador Engine) 1
2 4 Stroke Single Cylinder Petrol Engine With Mechanical Brake 1
3 4 Stroke Single Cylinder Diesel Engine With Electrical Brake 1
4 4 Twin Cylinder Diesel Engine With Mechanical Brake 1
5 Blower Test Rig 1
6 Single Stage Air Compressor Test Rig 1
7 R & AC Test Rig 1
8 Engler Viscometer 1
9 Saybolt Viscometer 1
10 Abel’s Apparatus 1
11 Cleveland’s Apparatus 1
12 Ramsbottom Apparatus 1
13 Junker’s Gas Calorimeter 1
14 Conradson Apparatus 1
15 Dead Weight Pressure Gauge Test Rig 1
16 Thurston Oil Tester 1
17 Two Stage Air Compressor Test Rig 1
18 3 Cylinder 4’Stroke Petrol Engine Test RIG (Maruti Engine) 1
19 Variable Compression Ratio Petrol Engine Test Rig 1
20 Two Stroke Petrol Engine Test Rig With Electrical Brake 1
21 Vortex Tube Apparatus 1
22 Critical Heat Flux Apparatus 1
23 Pf/Cf Heat Exchanger 1
24 Two Slab Guarded Hot Plate Apparatus 1
25 Stefan – Boltzmann Apparatus 1
26 Forced Convection Apparatus 1
27 Pin-Fin Apparatus 1
28 Emissivity Measurement Apparatus 1
29 Thermal Conductivity of Metal Rod Apparatus 1
30 Composite Wall Apparatus 1
31 Lagged Pipe Apparatus 1
32 Natural Convection Apparatus 1
33 Drop Wise and Film Wise Apparatus 1
34 Shell And Tube Heat Exchanger 1
35 Thermal Conductivity of Insulating Powder Apparatus 1
36 Recirculating Air Conditioning Test Rig 1
37 Solar Cooker 1
38 Pressure And Velocity Compounded Steam Turbine Model 1
METROLOGY & MEASUREMENTS LAB - List of Equipment
S. No. Name of the Equipment Quantity
1 Tool Maker`s Microscope 1
2 Electronic Comparator 1
3 Micrometers 4
4 Bevel Protractor 1
5 Gear Tooth Vernier 2
6 Snap Gauge 2
7 Height Gauge 1
8 Telescopic Gauge 1
9 Vernier Depth Gauge 2
10 Vernier Depth Micrometer 1
11 Angle Gauge 1
12 Flanged Micrometer 3
13 Dial Calipers 1
14 Sprit Level 2
15 Slip Gauges 2
16 Dial Indicator 8
17 Magnetic Stands 8
18 Vernier Calipers 4
19 Sine Bar 2
20 Flat Level 1
21 Screw Pitch Gauge 4
22 Straight Edge 1
23 Profile Projector 1
24 Surface Finish Tester 1
25 Magnifiers 4
26 Tool Kit 4
27 Surface Plate 3
28 Optical Flat With Monochromatic Light Source 1
29 Digital Vernier Caliper 1
30 Digital Stroboscope 1
31 Temperature Measuring Instrument 1
32 Strain Measuring Measurement 1
33 Displacement Measuring Measurement 1
34 Torque Measuring Measurement 1
35 Auto Collimator 1
36 Dial Indicators 4
37 Magnetic Stands 4
38 Flanged Micro Meters 2
MANUFACTURING LAB – List of Equipment
S. No. Name of the Equipment Quantity
1 Centre less Grinding Machine 1
2 Shaping Machine 2
3 Planing Machine 1
4 Alignment Test Lathe Machine 1
5 Milling Machines (Dynameters) 1
6 Slotting Machine 1
7 Surface Grinding Machine 1
8 Tool Cutting and Grinding Machine 1
9 Drilling Machine 2
10 Spanning Lathe Machine 2
11 Spanning Lathe Machine – 60 Tons 1
12 Fly Press 2
13 Power Saw Cutting Machine 1
14 Pillar Drilling Machine 1
15 Centre Lathe (1.3M) 5
16 Centre Lathe (1.5 M) 4
17 Centre Lathe (Heavy) – 12’ 1
18 Centre Lathe (Heavy) – 10’ 1
19 Centre Lathe (Heavy) – 8’ 1
20 Centre Lathe Machine – 6’ 2
21 HMT LB 17 Machine 2
22 Bench Grinding Machine 1
FOUNDRY & SAND TESTING LAB – List of Equipment
S. No. Name of the Equipment Quantity
1 Grain Fineness Test Machine 1
2 Universal Sand Testing Machine 1
3 Sand Rammer 1
4 Simple balance 1
5 Model of Cupola 1
6 Electric Oven 1
7 Crucible Furnace + Crucible Laddle with Handle 1
8 Sand Miller 1
9 Mould Boxes (Wooden) 10
10 Base Plates 8
11 Water Baskets 7
12 Mould Boxes (Big Size) (Wooden) 8 sets
DYNAMICS OF MACHINES LAB – List of Equipment
S. No. Name of the Equipment Quantity
1 Motorized Gyroscope 1
2 Balancing Equipment 1
3 Cam Analysis 1
4 Polariscope 1
5 Whirling Of Shaft 1
6 Journal Bearing 1
7 Universal Governor 1
INDUSTRIAL ENGINEERING LAB – List of Equipment
S. No. Name of the Equipment Quantity
1 Electrical Driven Tread Mill 1
2 Ergonomic Cycle – Hero Make 1
3 Ergonomic Cycle – Sharp Fit 1
4 Ergonomic Cycle – Finen World 1
5 Oxy Pulse Meter 1
6 Patient Monitor – 5 Para 12.5’ Color & TFT Screen 1
7 Digital Stop Watches 5
8 Finger Probe – Wellcor Type 1
9 Finger Probe – Fix to Finger 2

2.Research Labs

Metallurgy Lab – List of Equipment
S. No. Name of the Equipment Quantity
1 Jominy End Quench Apparatus 1
2 Specimen Mounting press with Digital measurements 2
3 Trinocular Microscopes with objective lens 4
4 Disc Polishing Machine 2
5 Muffle Furnace 1
CAM Lab – List of Equipment
S. No. Name of the Equipment Quantity
1 HP COMPUTER
AMD Phenom IIX4, 3.20 GHz, 4 GB RAM, 500GB HDD,
ZOTAC NVIDIA GeForce 210 Graphics Card, 19” LED Color Monitor,
Scroll Mouse, Keyboard
31
2 DELL COMPUTER
Dell Optimfix 740N, Process T800 Athlon X2 1500, 160GB HDD,
1GB DDR2 667 FSB RAM, Samsung 17” Monitor , Optical Mouse
4
3 ZENITH –PIV COMPUTER
P-IV 2.8HT, 256MB RAM, 40GB HDD, 10/100 Mbps NIC Card, 17” Color Monitor,
Scroll Mouse, M.M Keyboard
1
4 CNC LATHE MACHINE
CNC Slant Bed, Lathe (XL Turn)
1
5 CNC MILLING MACHINE
CNC Vertical Milling Centre (XL Turn)
1
6 AS/RS
Automatic Storage and Retrieval System
1
7 AGV
Automated Guided Vehicle
1
8 ASSEMBLY STATION 2
9 ROBO Kits 20
10 OPEN LABS Equipment 2
11 RP Machine 1
12 FANUC RobotLR Mate-100 Robot 1
13 Pick and place unitLoading and Unloading devices 1
Alternate Fuels Lab – List of Equipment
S. No. Name of the Equipment Quantity
1 Red Wood –Ii Viscometer 1
2 Pensky Martin Apparatus 1
3 Cloud and Pour Point Apparatus 1
4 Bomb Calorimeter 1
5 Smoke Point Apparatus 1
6 Computerized Diesel Engine Test Rig 1
7 Computer with Monitor and Key Board 1
8 Jet Test Facility
Production Lab – List of Equipment
S. No. Name of the Equipment Quantity
1 Capstan Lathes 2
2 Turret Lathes 1
3 Permeability Meter 1
4 Tungsten Inert Gas (TIG) Welding Apparatus 1
5 Metal Inert Gas (MIG) Welding Apparatus 1
6 Arc Welding Apparatus 1
Design Lab – List of Equipment
S. No. Name of the Equipment Quantity
1 Condition Monitoring Equipment 1
2 Vibrations Test Rig 1
Hydraulics Lab – List of Equipment
S. No. Name of the Equipment Quantity
1 Wind Tunnel 1
